Specifications
General
Color
Black
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Left Front: 1.8 kW (Boost - 2.3 kW)
• Left Rear: 1.8 kW (Boost - 2.3 kW)
• Left Sync Burner (Front + Rear): 3.4 kW (Boost - 3.6 kW)
• Right Front: 1.2 kW (Boost - 1.5 kW)
• Right Rear: 1.8 kW (Boost - 2.3 kW)
• Center: 2.3 kW (Boost - 4.3 kW)
• Left Rear: 1.8 kW (Boost - 2.3 kW)
• Left Sync Burner (Front + Rear): 3.4 kW (Boost - 3.6 kW)
• Right Front: 1.2 kW (Boost - 1.5 kW)
• Right Rear: 1.8 kW (Boost - 2.3 kW)
• Center: 2.3 kW (Boost - 4.3 kW)
Burner/Element Size
• Left Front: 7"
• Left Rear: 7"
• Left Sync Burner (Front + Rear): 7" x 15"
• Right Front: 6"
• Right Rear: 7"
• Center: 11"
• Left Rear: 7"
• Left Sync Burner (Front + Rear): 7" x 15"
• Right Front: 6"
• Right Rear: 7"
• Center: 11"
Elements
Smoothtop
Features
Digital Display
Yes
Additional Information
• Total Power: 8.9 kW
• 5-Element Cooktop with Sync Element
• Anti-Scratch Matte Glass Cooktop
• Digital Touch Controls
• 15 Power Levels + Boost Mode
• Wi-Fi Connectivity
• Hot Surface Indicator Light
• Safety Shutoff
• Pause
• Quick Stop
• Simmer
• Countdown Timer
• 5-Element Cooktop with Sync Element
• Anti-Scratch Matte Glass Cooktop
• Digital Touch Controls
• 15 Power Levels + Boost Mode
• Wi-Fi Connectivity
• Hot Surface Indicator Light
• Safety Shutoff
• Pause
• Quick Stop
• Simmer
• Countdown Timer
Electrical Information
Information
240V / 60 Hz / 40A
Certifications and Approvals
Information
EnergyStar
Dimensions
Class Width
36"
Width
36 inch(es) / 91.44 cm
Height
4.13 inch(es) / 10.48 cm
Depth
21.25 inch(es) / 53.98 cm
Weight
46.3 lb(s) / 21 kg
Additional Dimensions
Cooktop Cutout Dimensions: 33 7/8 "– 34" x 4 1/8" x 19 1/8" – 19 3/16"
Shipping Dimensions
Width
40.13 inch(es) / 101.92 cm
Height
9.06 inch(es) / 23.02 cm
Depth
25.13 inch(es) / 63.82 cm
Weight
51.61 lb(s) / 23.41 kg
Warranty
Warranty
1-Year parts and labor
UPC
UPC#
887276990316
