Features
HOUSEHOLD SIZE
Provide hot water for the whole family of 2 to 4 persons
INLET TUBE
Replenishes water from the bottom of the tank to maximize hot water delivery.
BRASS DRAIN VALVE
Rust-proof construction can be counted on to provide long-lasting service.
ANODE ROD
Durable design extends the life of your water heater with long-lasting protection against corrosion.
BUILT-IN WiFi
Easily adjust temperatures, set vacation mode schedules and receive notifications with Built-in WiFi powered by SmartHQ
DIGITAL DISPLAY
Make easy, accurate adjustments at the touch of a button.
EASY SET UP
Replace your old water heater quickly and easily using standard water and electrical connections.
Additional Features
ECOPORT CERTIFIED CTA-2045
Utility-ready for demand response programs, helps reduce peak energy loads and supports grid stability. Solution for smart energy management.
Specifications
General
Type
Tall
Model Type
Residential
Fuel Type
Electric
Installation
Floorstanding
Color
Grey
Certifications and Approvals
Certifications
EcoPort Certified CTA-2045
Features
Controls
Electronic with Digital Display
Additional Information
• Unit Capacity: 50 Gallons
• Connected Capabilities: Amazon Alexa, Google Home
• Diagnostic Feedback
• Drain Valve Type: Brass
• Family Size: 3-5 People
• Operating Modes: Normal, Vacation
• Overheat Protection
• Temperature Setting: 100-140° F Range
• Temperature Setting Factory Default: 120° F
• Water Connection Location: Top
• WiFi Connect: Built-In
• Electrical Circuit Required: Dedicated 30 Amp Min.
• Electrical Connection: Direct-Wire
• Energy Consumption (kWh/year): 5334
• First Hour Rate (FHR): 78 Gallons
• Heating - Electric - Heater Watts: 5500/5500
• Integrated Energy Factor: 0.93
• Operating Water Pressure: 20-125 PSI
• Voltage (MAX): 240 V
• Volts/Hertz: 240V; 60Hz
• Connected Capabilities: Amazon Alexa, Google Home
• Diagnostic Feedback
• Drain Valve Type: Brass
• Family Size: 3-5 People
• Operating Modes: Normal, Vacation
• Overheat Protection
• Temperature Setting: 100-140° F Range
• Temperature Setting Factory Default: 120° F
• Water Connection Location: Top
• WiFi Connect: Built-In
• Electrical Circuit Required: Dedicated 30 Amp Min.
• Electrical Connection: Direct-Wire
• Energy Consumption (kWh/year): 5334
• First Hour Rate (FHR): 78 Gallons
• Heating - Electric - Heater Watts: 5500/5500
• Integrated Energy Factor: 0.93
• Operating Water Pressure: 20-125 PSI
• Voltage (MAX): 240 V
• Volts/Hertz: 240V; 60Hz
Dimensions
Width
22 inch(es) / 55.88 cm
Height
63.75 inch(es) / 161.92 cm
Depth
22 inch(es) / 55.88 cm
Weight
142 lb(s) / 64.41 kg
Shipping Dimensions
Width
23.1 inch(es) / 58.67 cm
Height
65.5 inch(es) / 166.37 cm
Depth
24.3 inch(es) / 61.72 cm
Weight
153.99 lb(s) / 69.85 kg
Warranty
Warranty
• Labor Warranty: Limited 1-year entire appliance
• Parts Warranty: Limited 10-year tank and parts
• Parts Warranty: Limited 10-year tank and parts
UPC
UPC#
084691916130
