Features
HOUSEHOLD SIZE
Provide hot water for the whole family of 2 to 4 persons
BRASS DRAIN VALVE
Rust-proof construction can be counted on to provide long-lasting service.
POWER VENT
Get easy, anywhere venting. Gas power vent water heaters offer flexible venting options with lengths up to 150 feet and either vertical or horizontal termination.
SMARTSHIELD ™ SAFETY SYSTEM
Monitors the surrounding air and automatically shuts off the unit if abnormal temperatures are detected.
SELF-DIAGNOSTIC
Monitors and reports on gas system status via LED status indicator.
MADE IN AMERICA
Get the added confidence of an American-made water heater.
Specifications
General
Type
Short
Model Type
Residential
Fuel Type
Natural Gas
Installation
Floorstanding
Color
Grey
Features
Controls
LED Indicator
Additional Information
• Unit Capacity: 50 Gallons
• Anode Rod: Magnesium
• Bin Testing: High
• Drain Valve Type: Brass
• Family Size: 3-5 or more People
• FVIR Safety System: Prevents accidental ignition of flammable vapors
• Gas Valve: Self-Powered
• Overheat Protection: Dry Burning Protection
• Pilot Light Window / Button
• Product Type: Power Vent Gas
• Temp & Pressure Relief Valve
• Temperature Setting: 45-160° F Range
• UEF: 0.61
• Water Connection Location: Top
• Burner BTU Size (k): 40
• First Hour Delivery GPH: 73 gal/h
• Vent Size: 3" Type B Vent
• Anode Rod: Magnesium
• Bin Testing: High
• Drain Valve Type: Brass
• Family Size: 3-5 or more People
• FVIR Safety System: Prevents accidental ignition of flammable vapors
• Gas Valve: Self-Powered
• Overheat Protection: Dry Burning Protection
• Pilot Light Window / Button
• Product Type: Power Vent Gas
• Temp & Pressure Relief Valve
• Temperature Setting: 45-160° F Range
• UEF: 0.61
• Water Connection Location: Top
• Burner BTU Size (k): 40
• First Hour Delivery GPH: 73 gal/h
• Vent Size: 3" Type B Vent
Dimensions
Width
25 inch(es) / 63.50 cm
Height
54 inch(es) / 137.16 cm
Depth
25 inch(es) / 63.50 cm
Weight
173 lb(s) / 78.47 kg
Shipping Dimensions
Width
26 inch(es) / 66.04 cm
Height
56.5 inch(es) / 143.51 cm
Depth
28.4 inch(es) / 72.14 cm
Weight
187 lb(s) / 84.82 kg
Warranty
Warranty
• Labor Warranty: Limited 1-year entire appliance
• Parts Warranty: Limited 8-year tank and parts
• Parts Warranty: Limited 8-year tank and parts
UPC
UPC#
084691944713
