Features
HOUSEHOLD SIZE
Provide hot water for the whole family of 2 to 4 persons
EASY SET UP
Replace your old water heater quickly and easily using standard water and electrical connections.
INLET TUBE
Replenishes water from the bottom of the tank to maximize hot water delivery.
BUILT-IN WiFi
Easily adjust temperatures, set vacation mode schedules and receive notifications with Built-in WiFi powered by SmartHQ
QUICK RECOVERY
Two 5500W heating elements quickly increase water temperature for hot water when you need it.
DIGITAL DISPLAY
Make easy, accurate adjustments at the touch of a button.
FLEXIBLE CAPACITY
Choose from three capacity settings to enjoy up to 60% additional hot water when you need it* *vs comparable water heaters without mixing valve at 120°F set and 58°F water temperature.
STAINLESS STEEL HEATING ELEMENTS
Ultra-durable stainless-steel heating elements resist rust and corrosion
BRASS DRAIN VALVE
Rust-proof construction can be counted on to provide long-lasting service.
ANODE SENSING
Notifies you when your anode rod needs replacing to help extend the life of your tank
Additional Features
ECOPORT CERTIFIED CTA-2045
Utility-ready for demand response programs, helps reduce peak energy loads and supports grid stability. Solution for smart energy management.
Specifications
General
Type
Short
Model Type
Residential
Fuel Type
Electric
Installation
Floorstanding
Color
Grey
Certifications and Approvals
Certifications
EcoPort Certified CTA-2045
Features
Controls
Electronic with Digital Display
Additional Information
• Effective Capacity at X-High Setting (gallons): 80
• Unit Capacity: 50 Gallons
• Connected Capabilities: Amazon Alexa, Google Home
• Diagnostic Feedback
• Drain Valve Type: Brass
• Effective Capacity Settings: Normal/High/X-High Flexible Capacity
• Electronic, Integrated Mixing Valve
• Family Size: 3-5 People / 5-6 People
• Operating Modes: Normal, Vacation
• Overheat Protection
• Product Type: Electric Flexible Capacity
• Temperature Setting: 100-140° F Range
• Temperature Setting Factory Default: 120° F
• Water Connection Location: Top
• WiFi Connect: Built-In
• Electrical Circuit Required: 208V/240V 60 Hz Dedicated 30 Amp Min
• Electrical Connection: Direct-Wire
• Element Type: Stainless Steel
• Energy Consumption (kWh/year): 5334
• First Hour Rate (FHR): 75 Gallons
• Heating - Electric - Heater Watts: 5500/5500
• Integrated Energy Factor: 0.93
• Operating Water Pressure: 20-125 PSI
• Voltage (MAX): 240 V
• Volts/Hertz: 240V; 60Hz
• Unit Capacity: 50 Gallons
• Connected Capabilities: Amazon Alexa, Google Home
• Diagnostic Feedback
• Drain Valve Type: Brass
• Effective Capacity Settings: Normal/High/X-High Flexible Capacity
• Electronic, Integrated Mixing Valve
• Family Size: 3-5 People / 5-6 People
• Operating Modes: Normal, Vacation
• Overheat Protection
• Product Type: Electric Flexible Capacity
• Temperature Setting: 100-140° F Range
• Temperature Setting Factory Default: 120° F
• Water Connection Location: Top
• WiFi Connect: Built-In
• Electrical Circuit Required: 208V/240V 60 Hz Dedicated 30 Amp Min
• Electrical Connection: Direct-Wire
• Element Type: Stainless Steel
• Energy Consumption (kWh/year): 5334
• First Hour Rate (FHR): 75 Gallons
• Heating - Electric - Heater Watts: 5500/5500
• Integrated Energy Factor: 0.93
• Operating Water Pressure: 20-125 PSI
• Voltage (MAX): 240 V
• Volts/Hertz: 240V; 60Hz
Dimensions
Width
24 inch(es) / 60.96 cm
Height
61 inch(es) / 154.94 cm
Depth
24 inch(es) / 60.96 cm
Weight
159.99 lb(s) / 72.57 kg
Shipping Dimensions
Width
25.1 inch(es) / 63.75 cm
Height
62.7 inch(es) / 159.26 cm
Depth
26.3 inch(es) / 66.80 cm
Weight
170.99 lb(s) / 77.56 kg
Warranty
Warranty
• Labor Warranty: Limited 1-year entire appliance
• Parts Warranty: Limited 10-year tank and parts
• Parts Warranty: Limited 10-year tank and parts
UPC
UPC#
084691916147
