Features
HOUSEHOLD SIZE
Provide hot water for the whole family of 2 to 4 persons
BRASS DRAIN VALVE
Rust-proof construction can be counted on to provide long-lasting service.
POWER VENT
Get easy, anywhere venting. Gas power vent water heaters offer flexible venting options with lengths up to 150 feet and either vertical or horizontal termination.
SMARTSHIELD ™ SAFETY SYSTEM
Monitors the surrounding air and automatically shuts off the unit if abnormal temperatures are detected.
SELF-DIAGNOSTIC
Monitors and reports on gas system status via LED status indicator.
MADE IN AMERICA
Get the added confidence of an American-made water heater.
Specifications
General
Type
Tall
Model Type
Residential
Fuel Type
Liquid Propane
Installation
Floorstanding
Color
Grey
Features
Controls
LED Indicator
Additional Information
• Unit Capacity: 40 Gallons
• Altitude Rating: 10,100 ft
• Anode Rod: Magnesium
• Bin Testing: High
• Drain Valve Type: Brass
• Family Size: 2-5 People
• FVIR Safety System: Prevents accidental ignition of flammable vapors
• Gas Valve: Self-Powered
• Overheat Protection: Dry Burning Protection
• Pilot Light Window / Button
• Product Type: Power Vent Gas
• Temp & Pressure Relief Valve
• Temperature Setting: 45-160° F Range
• UEF: 0.62
• Water Connection Location: Top
• Burner BTU Size (k): 38
• First Hour Delivery GPH: 68 gal/h
• Vent Size: 3" Type B Vent
• Altitude Rating: 10,100 ft
• Anode Rod: Magnesium
• Bin Testing: High
• Drain Valve Type: Brass
• Family Size: 2-5 People
• FVIR Safety System: Prevents accidental ignition of flammable vapors
• Gas Valve: Self-Powered
• Overheat Protection: Dry Burning Protection
• Pilot Light Window / Button
• Product Type: Power Vent Gas
• Temp & Pressure Relief Valve
• Temperature Setting: 45-160° F Range
• UEF: 0.62
• Water Connection Location: Top
• Burner BTU Size (k): 38
• First Hour Delivery GPH: 68 gal/h
• Vent Size: 3" Type B Vent
Dimensions
Width
20 inch(es) / 50.80 cm
Height
66.33 inch(es) / 168.48 cm
Depth
20 inch(es) / 50.80 cm
Weight
142 lb(s) / 64.41 kg
Shipping Dimensions
Width
21 inch(es) / 53.34 cm
Height
68.7 inch(es) / 174.50 cm
Depth
23.4 inch(es) / 59.44 cm
Weight
153.99 lb(s) / 69.85 kg
Warranty
Warranty
• Labor Warranty: Limited 1-year entire appliance
• Parts Warranty: Limited 8-year tank and parts
• Parts Warranty: Limited 8-year tank and parts
UPC
UPC#
084691944652
